Enclosure size
Power [HP]
Current rating
Recommended
fuse size
Recommended
maximum fuse
Recommended
circuit breaker
Danfoss
Maximum trip
level [A]
B2
15
gG-25
gG-63
20
gG-25
gG-63
25
gG-32
30
gG-32
C2
40
gG-40
50
gG-63
gG-80
60
gG-63
gG-100
75
gG-80
gG-125
100
gG-100
gG-160
C3
50
gG-100
gG-125
60
gG-125
gG-160
UL and cUL branch circuit protection fuses
For compliance with UL and cUL electrical standards, the following fuses or UL/cUL
approved substitutions are required. Maximum fuse ratings are listed.
Table 42: UL fuses, 208–230V and 380–600 V
Frequency
converter
Bussman
Bussman
Bussman
SIBA
Littel fuse
Ferraz-Shawmut Ferraz-Shawmut
208–230 V
[HP]
Type RK1
Type J
Type T
Type RK1
Type RK1
Type CC
Type RK1
0015
KTN-R10
JKS-10
JJN-10
5017906-010
KLN-R10
ATM-R10
A2K-10R
0020
KTN-R15
JKS-15
JJN-15
5017906-015
KLN-R15
ATM-R15
A2K-15R
0030
KTN-R20
JKS-20
JJN-20
5012406-020
KLN-R20
ATM-R20
A2K-20R
0050
KTN-R30
JKS-30
JJN-30
5012406-030
KLN-R30
ATM-R30
A2K-30R
0075
KTN-R50
JKS-50
JJN-50
5012406-050
KLN-R50
—
A2K-50R
0100
KTN-R50
JKS-60
JJN-60
5012406-050
KLN-R60
—
A2K-50R
0150
KTN-R60
JKS-60
JJN-60
5014006-063
KLN-R60
A2K-60R
A2K-60R
0200
KTN-R80
JKS-80
JJN-80
5014006-080
KLN-R80
A2K-80R
A2K-80R
0250
KTN-R125
JKS-150
JJN-125
2028220-125
KLN-R125
A2K-125R
A2K-125R
0300
KTN-R125
JKS-150
JJN-125
2028220-125
KLN-R125
A2K-125R
A2K-125R
0400
FWX-150
—
—
2028220-150
L255-150
A25X-150
A25X-150
0500
FWX-200
—
—
2028220-200
L25S-200
A25X-200
A25X-200
0600
FWX-250
—
—
2028220-250
L25S-250
A25X-250
A25X-250
380–460 V, 575 V
[HP]
Type RK1
Type J
Type T
Type RK1
Type RK1
Type CC
Type RK1
0015
KTS-R6
JKS-6
JJS-6
5017906–006
KLS-R6
ATM-R6
A6K-6R
0020–0030
KTS-R10
JKS-10
JJS-10
5017906–010
KLS-R10
ATM-R10
A6K-10R
0050
KTS-R20
JKS-20
JJS-20
5017906–020
KLS-R20
ATM-R20
A6K-20R
0075
KTS-R25
JKS-25
JJS-25
5017906–025
KLS-R25
ATM-R25
A6K-25R
0050
KTS-R100
JKS-100
JJS-100
2028220–125
KLS-R100
A6K-100R
0100
KTS-R30
JKS-30
JJS-30
5012406–032
KLS-R30
ATM-R30
A6K-30R
0150
KTS-R40
JKS-40
JJS-40
5014006–040
KLS-R40
—
A6K-40R
