Table 40: EN50178 fuses 200 V to 480 V
Frequency converter Maximum fuse size Voltage Type
208–230 V — T2
0015–0020
16A 1) 200–240 type gG
0030 25A 1) 200–240 type gG
0050 35A 1) 200–240 type gG
0075 50A 1) 200–240 type gG
0100 63A 1) 200–240 type gG
0150 63A 1) 200–240 type gG
0200 80A 1) 200–240 type gG
0250 125A 1) 200–240 type gG
0300 125A 1) 200–240 type gG
0400 160A 1) 200–240 type gG
0500 200A 1) 200–240 type aR
0600 250A 1) 200–240 type aR
380–460 V — T4
0015–0020
10A 1) 380–500 type gG
0030 16A 1) 380–500 type gG
0050–0075 25A 1) 380–500 type gG
0100 35A 1) 380–500 type gG
0150–0200 63A 1) 380–500 type gG
0250 63A 1) 380–500 type gG
0300 63A 1) 380–500 type gG
0400 80A 1) 380–500 type gG
0500 100A 1) 380–500 type gG
0600 125A 1) 380–500 type gG
0750 160A 1) 380–500 type gG
1000 250A 1) 380–500 type aR
1250 250A 1) 380–500 type aR
1) Maximum fuses see national/international regulations for selecting an applicable fuse
size.
Table 41: 525–690 V, Frame sizes A, C, D, E and F (non-UL fuses)
Enclosure size Power [HP] Current rating Recommended
fuse size
Recommended
maximum fuse
Recommended
circuit breaker
Danfoss
Maximum trip
level [A]
A3
1.5 gG-6 gG-25 CTI25M 10–16 16
2 gG-6 gG-25 CTI25M 10–16 16
3 gG-6 gG-25 CTI25M 10–16 16
5 gG-10 gG-25 CTI25M 10–16 16
7.5 gG-16 gG-25 CTI25M 10–16 16
10 gG-16 gG-25 CTI25M 10–16 16
