Frequency type designation
0500
0600
0750
1000
1250
Estimated power loss at rated maximum load [A]
4)
739
843
1083
1384
1474
IP20 maximum cable cross-section (mains, brake, motor, and load
sharing)
50 (1)
150 (300 MCM)
IP21, IP55, IP66 maximum cable cross-section (mains, motor) [mm
2
/
(AWG)]
150 (300 MCM)
IP21, IP55, IP66 maximum cable cross-section (brake, load sharing)
[mm
2
/(AWG)]
95 (3/0)
With mains disconnect switch included:
35/2
35/2
70/3/0
185/
kcmil350
Weight enclosure IP20 [kg]
23.5
35
35
50
50
Weight enclosure IP21 [kg]
45
45
45
65
65
Weight enclosure IP55 [kg]
45
45
45
65
65
Weight enclosure IP66 [kg]
45
45
45
65
65
Efficiency
3)
0.98
0.98
0.98
0.98
0.98
Table 38: Mains supply 3 x 525–600 V AC Normal overload 110% for 1 minute, 1.5HP - 15HP
Frequency type designation
0015
0020
0030
0050
0075
0100
0150
Typical shaft output [HP]
1.5
2
3
5
7.5
10
15
IP20/Chassis
A3
A3
A3
A3
A3
A3
B3
IP21/NEMA 1
A3
A3
A3
A3
A3
A3
B1
IP55/Type 12
A5
A5
A5
A5
A5
A5
B1
IP66/NEMA 4X
A5
A5
A5
A5
A5
A5
B1
Output current
Continuous (3 x 525–550 V) [A]
2.6
2.9
4.1
6.4
9.5
11.5
19
Intermittent (3 x 525–550 V) [A]
2.9
3.2
4.5
7.0
10.5
12.7
21
Continuous (3 x 525–600 V) [A]
2.4
2.7
3.9
6.1
9.0
11.0
18
Intermittent (3 x 525–600 V) [A]
2.6
3.0
4.3
6.7
9.9
12.1
20
Continuous kVA (525 V AC) [kVa]
2.5
2.8
3.9
6.1
9.0
11.0
18.1
Continuous kVA (575 V AC) [kVA]
2.4
2.7
3.9
6.1
9.0
11.0
17.9
Maximum input current
Continuous (3 x 525–600 V) [A]
2.4
2.7
4.1
5.8
8.6
10.4
16.2
Intermittent (3 x 525–600 V) [A]
2.7
3.0
4.5
6.4
9.5
11.5
19
Additional specifications
Estimated power loss at rated maximum load [W]
4)
50
65
92
145
195
261
300
IP20 maximum cable cross-section (mains, motor, brake, and load sharing)
[mm
2
]/[AWG]
4, 4, 4 (12, 12, 12)
(minimum 0.2 (24))
IP55, IP66 maximum cable cross-section (mains, motor, brake, and load
sharing) [mm
2
]/[AWG]
4, 4, 4 (12, 12, 12)
(minimum 0.2 (24))
Maximum cable cross-section with disconnect
6, 4, 4 (12, 12 ,12)
Mains disconnect switch included:
4/12
Weight IP20 [kg]
6.5
6.5
6.5
6.5
6.6
6.6
12
Wright IP21/55 [kg]
13.5
13.5
13.5
13.5
14.2
14.2
23
Efficiency
4)
0.97
0.97
0.97
0.97
0.97
0.97
0.98
