background image

Operating Instruction

9

4

Technical Data - Frequency Inverter And General Data

TECHNOVAR

Technovar

output to

the Motor

Supply Voltage

Model

No.

nominal

Horsepower

Max. Current

HV 2.1

2

7 A

*1x220...240VAC ±15%

HV 2.2

3

10 A

*1x220...240VAC ±15%

HV 3.2

3

5,7 A

3x380...460VAC ±15%

HV 3.3

4

7,3 A

3x380...460VAC ±15%

HV 3.4

5

9 A

3x380...460VAC ±15%

HV 3.5

7.5

13,5 A

3x380...460VAC ±15%

HV 3.7

10

17 A

3x380...460VAC ±15%

HV 3.11

15

23 A

3x380...460VAC ±15%

HV 3.15

20

30 A

3x380...460VAC ±15%

HV 3.18

25

37 A

3x380...460VAC ±15%

HV 3.22

30

43 A

3x380...460VAC ±15%

Note: Consult local authorities in your jurisdiction for fuse sizing.
* Output voltage is 3 phase and requires a motor suitable for 220-240V/3/60 input power

Mains frequency:

48....62 Hz

Max. frequency:

See chapter 10.8

Min. frequency:

0 – f-max see chapter 10.9

Electrical efficiency:

> 95%

Please

Note!

If the motor and control unit are assembled separately keep the
motor cable as short as possible in order to avoid electromagnetic

emissions and capacitive currents. The length may not exceed 66 m.
and a shielded cable has to be used.

Protection against: Short circuit, under- and over voltage, overheating of the electronics
(overload) and additional external protective functions via PTC (motor temperature) and

low water switch.
A mains filter is fitted to ensure interference immunity.
