Operating Instruction
46
11. SAVE ???
SAVED
appears on the display. After five
seconds the display jumps back to the
1
st display.
These parameters can also be set during operation; To do so, briefly press the
button and repeat steps 1 – 10.
Please Note: often shown display
12. INVERTER LOCKED
enable inverter
This message appears when the connection of
terminal X1/4-X1/5 is open (external release contact).
10 Settings at Secondary Menu
Important: Before entering the secondary menu these instructions must
be read carefully to prevent incorrect settings which will cause
malfunction.
Secondary Menu:
Stop motor by pressing OFF
INVERTER STOP
ON -> START
Press for 3 seconds to change to
PASSWORD
0000
Set ‘Password 0066’ by pressing
PASSWORD
0066
Confirm by pressing and the first
window of the sub menu is shown
J O G – MODE
0.0Hz X.XX psi
In the following paragraphs all possible settings are listed (in the display, there is
shown the European default setting).
10.1 JOG-MODE
Display and Manual Operation Mode
J O G – MODE
0.0Hz X.XX psi
Actual outgoing frequency and actual analog input are
shown. By pressing or in this menu, the
Note: The password must be entered at each entry
