Bell & Gossett 193 TECHNOVAR VARIABLE SPEED PUMP CONTROLLER AND INTEGRATED AJUSTABLE FREQUENCY DRIVE User Manual
Page 69
Operating Instruction
69
ERROR 1
..............
Last error
ERROR 2
..............
4
th
recorded ERROR
ERROR 3
..............
3
rd
recorded ERROR
ERROR 4
..............
2
nd
recorded ERROR
ERROR 5
..............
1
st
recorded ERROR
TOTAL RUN TIME
0000:00
Total motor run time hh:mm
SAVE ???
+
Press [ + ] to save parameter values
PASSWORD
0000
Enter Password
JOG - MODE
0.0Hz xx.xx psi
JOG MODE: Frequency controlled by [ ] or [ ];
(no control)
W I N D O W
5%
Desired window width around the desired value
(in % from the desired value)
RAMP HYSTERESIS
80%
% of half desired window width related to hysteresis
RAMP 1
4.0 Sec
Ramp 1: acceleration time
(actual value outside operating window)
RAMP 2
4.0 Sec
Ramp 2: deceleration time
(actual value outside operating window)
RAMP 3
70 Sec
Ramp 3: acceleration time
(actual value within window)
RAMP 4
70 Sec
Ramp 4: deceleration time
(actual value within window)
