Bell & Gossett 193 TECHNOVAR VARIABLE SPEED PUMP CONTROLLER AND INTEGRATED AJUSTABLE FREQUENCY DRIVE User Manual
Page 23
Operating Instruction
23
6.1.3 Mounting the thermistor
Variant A:
Variant B:
1. Open the cover of the conduit box and remove also the terminal block inside.
2. Fix the thermistor (Variant A or B)
3. Electrical connection of the motor cables see chapter 6.2.
4. Electrical connection to the Technovar see chapter 6.2
motor
thermistor
terminal block
rubber gasket
cover of the
conduit box
Thermistor
