Bell & Gossett 193 TECHNOVAR VARIABLE SPEED PUMP CONTROLLER AND INTEGRATED AJUSTABLE FREQUENCY DRIVE User Manual
Page 18
Operating Instruction
18
Afterwards replace the top cover and be careful with the connection cable to the display and the
Earth-cable. At last fix the 3 screws of the top cover.
In Pictures 8 and 9 you can see the Technovar with the mounted wallmounting-kit.
Mark the 4 holes according to the dimension drawing (see next page) on the wall and drill it with a
drilling machine. Mount the whole Technovar unit on the wall by using suitable screws.
Dimension drawing (HV2.1-3.4) (inches)
Dimension drawing (HV3.5-3.11
)
