5
Dimensions and Weights
HV2.1/2.2/3.2/3.3/3.4 HV 3.5/3.7/3.11
all measurements in inches
Motorfancover max. 7.9 Ø
Type:
Weight: Type:
Weight:
[lbs]
[lbs]
HV 2.1
13
HV 3.4
13
HV 2.2
13
HV 3.5
22
HV 3.2
13
HV 3.7
22
HV 3.3
13
HV 3.11 22
Type
Weight
[lbs]
HV3.15
64
HV3.18
64
HV3.22
64
Motorfancover max. 15.2 Ø
HV 3.15/ 3.18/ 3.22
