Bell & Gossett 193 TECHNOVAR VARIABLE SPEED PUMP CONTROLLER AND INTEGRATED AJUSTABLE FREQUENCY DRIVE User Manual
Page 19
Operating Instruction
19
Wall mounting – kit 15/22kW
Picture 1
Picture 2
E
Included Components for wallmounted kit
4
long screw M6x25
Picture 1 A
4
washer
Picture 1 B
4
short screw M6x12
Picture 1 C
4
washer
Picture 1 D
1
AC-fan incl. connection cable
Picture 2
1
fan board incl. 3 fuses T 1A/500V
Picture 3 and 3 G
2
cable connector
Picture 7
1
2 wire cable with connector
Picture 7 and 8
1
cable gland for fan-cable
Picture 12
1
wallmounted component
Picture 13
A
B D
F
F
C
