Bell & Gossett 193 TECHNOVAR VARIABLE SPEED PUMP CONTROLLER AND INTEGRATED AJUSTABLE FREQUENCY DRIVE User Manual
Page 25
Operating Instruction
25
6.3
Main Voltage Terminals
supply cable
The main power cable is connected to the terminals labeled L1, N for the 1x230 VAC, single
phase unit or L1, L2, L3 for the 3x400VAC, three phase unit.
Power supply
1x230 VAC
Motor connection
Control terminals
RS485 interface
Power supply
3x400 VAC
Motor connection
RS485 interface
Control terminals
HV2.1 / HV2.2
HV 3.2 – 3.11
RS485 interface
Motor connection
Control
terminals
Power supply
3x400 VAC
HV 3.15/ 3.18/ 3.22
