Operating Instruction
54
LEVEL 1
XX.X %
The level 1 is the start level of the 1
st
Offset.
(adjustable between 0 and 100% of the additional
analog input).
Press on the Technovar to change to
10.21.3 2
nd
Offset level
LEVEL 2
XX.X %
The level 2 is the start level of the 2
nd
Offset.
(adjustable between 0 and 100% of the additional
analog input).
Press on the Technovar to change to
10.21.4 INTENSITY 1
INTENSITY 1
+XX.X %
This is the intensity of the 1
st
Offset of the required
value at the zero point of the second analog input
Setting range: -200% up to +200% of the sensor range.
Press on the Technovar to change to
10.21.5 INTENSITY 2
INTENSITY 2
+XX.X %
This is the intensity of the 2
nd
Offset of the required
value at the maximum point of the second analog
Input. Setting range: -200% up to +200% of the sensor range.
To leave the submenu press the longer than 3 sec. to change to
S U B M E N U
Offset
Press on the Technovar to change to
10.22 Submenu Sequence control
S U B M E N U
Seq. Control
Programming Sequential Operations
Up to four pumps can be connected using the integrated RS-485 interface (Connection of the
terminals /1, /2 and /3 of the terminal blocks X5 or X6 of each pump together). However, the
following additional programming must be carried out in the submenu:
