Bell & Gossett 193 TECHNOVAR VARIABLE SPEED PUMP CONTROLLER AND INTEGRATED AJUSTABLE FREQUENCY DRIVE User Manual
Page 68
Operating Instruction
68
BIT0...BIT7
Inverter fault
BIT8
Free
BIT9
fist BIT10 Pump Stop/Start BIT11 Pump runs BIT12 lead/lag operation active (activ=1) 1F Control Word: 0000 Inverter stop 0001 Inverter start 0002 Parameter – Save 0100 Master overrules 0200 Requirement reset 0300 Master overrules and requirement reset For further information see: serial data transmission – RS485 TECHNOVAR – Protocol 120 13 Auxiliary Texts All auxiliary texts that are available in texts in the display window are listed here. To call them Window Text: Auxiliary Text: ITT INDUSTRIES x.xx psi No auxiliary text available! Pressing buttons and provides LANGUAGE SELECTION REQUIRED VALUE x.xx psi Input or displayed of the desired value REQUIRED VALUE 2 x.xx psi Input or displayed of the desired value 2 AUTO – START OFF ON -> Autostart enabled; OFF -> Autostart disabled
up press the buttons + ; each auxiliary text then appears as "running text" in the second
line of the window.
