40
AC06
...Repeated for module number 7
AC07
...Repeated for module number 8
AC08
...Repeated for module number 9
AC09
...Repeated for module number 10
AC0A
...Repeated for module number 11
AC0B
...Repeated for module number 12
AC0C
...Repeated for module number 13
AC0D
...Repeated for module number 14
AC0E
...Repeated for module number 15
AC0F
...Repeated for module number 16
AC10
...Repeated for module number 17
AC11
...Repeated for module number 18
AC12
...Repeated for module number 19
AC13
...Repeated for module number 20
AC14
...Repeated for module number 21
AC15
...Repeated for module number 22
AC16
...Repeated for module number 23
AC17
...Repeated for module number 24
AC18
...Repeated for module number 25
AC19
...Repeated for module number 26
AC1A
...Repeated for module number 27
AC1B
...Repeated for module number 28
AC1C
...Repeated for module number 29
AC1D
...Repeated for module number 30
AC1E
...Repeated for module number 31
AC1F
...Repeated for module number 32
Digital I/O States (Read Only)
B200
Virtual Input States (2 items)
0 to 65535
---
1
F500
0
B202
Reserved (30 items)
0 to 65535
---
1
F500
0
B220
Virtual Output States (8 items)
0 to 65535
---
1
F500
0
B228
Reserved (30 items)
0 to 65535
---
1
F500
0
B246
Contact Input States (8 items)
0 to 65535
---
1
F500
0
B24E
Reserved (8 items)
0 to 65535
---
1
F500
0
B256
Contact Output States (8 items)
0 to 65535
---
1
F500
0
B25E
Reserved (162 items)
0 to 65535
---
1
F500
0
Flexlogic Status (Read Only)
B320
Flexlogic Status Message
---
---
---
F200
(none)
Breaker Control (Read/Write Setting) (30 modules)
B400
Breaker Control x Open Flux Shifter
0 to 65535
---
1
F300
0
B401
Breaker Control x Open Shunt Trip
0 to 65535
---
1
F300
0
B402
Breaker Control x Trip Flux Shifter
0 to 65535
---
1
F300
0
B403
Breaker Control x Trip Shunt Trip
0 to 65535
---
1
F300
0
B404
Breaker Control x Close
0 to 65535
---
1
F300
0
