27
1EC0
...Repeated for module number 15
1EE0
...Repeated for module number 16
1F00
...Repeated for module number 17
1F20
...Repeated for module number 18
1F40
...Repeated for module number 19
1F60
...Repeated for module number 20
1F80
...Repeated for module number 21
1FA0
...Repeated for module number 22
1FC0
...Repeated for module number 23
1FE0
...Repeated for module number 24
2000
...Repeated for module number 25
2020
...Repeated for module number 26
2040
...Repeated for module number 27
2060
...Repeated for module number 28
2080
...Repeated for module number 29
20A0
...Repeated for module number 30
Energy (Read Only Non-Volatile) (30 modules)
2100
Positive Watthour
0 to
1000000000000
Wh
0.001
F060
0
2102
Phase A Positive Watthour
0 to
1000000000000
Wh
0.001
F060
0
2104
Phase B Positive Watthour
0 to
1000000000000
Wh
0.001
F060
0
2106
Phase C Positive Watthour
0 to
1000000000000
Wh
0.001
F060
0
2108
Negative Watthour
0 to
1000000000000
Wh
0.001
F060
0
210A
Phase A Negative Watthour
0 to
1000000000000
Wh
0.001
F060
0
210C
Phase B Negative Watthour
0 to
1000000000000
Wh
0.001
F060
0
210E
Phase C Negative Watthour
0 to
1000000000000
Wh
0.001
F060
0
2110
Positive Varhour
0 to
1000000000000
varh
0.001
F060
0
2112
Phase A Positive Varhour
0 to
1000000000000
varh
0.001
F060
0
2114
Phase B Positive Varhour
0 to
1000000000000
varh
0.001
F060
0
2116
Phase C Positive Varhour
0 to
1000000000000
varh
0.001
F060
0
2118
Negative Varhour
0 to
1000000000000
varh
0.001
F060
0
211A
Phase A Negative Varhour
0 to
1000000000000
varh
0.001
F060
0
211C
Phase B Negative Varhour
0 to
1000000000000
varh
0.001
F060
0
211E
Phase C Negative Varhour
0 to
1000000000000
varh
0.001
F060
0
2120
Vahour
0 to
1000000000000
vah
0.001
F060
0
2122
Phase A Vahour
0 to
1000000000000
vah
0.001
F060
0
2124
Phase B Vahour
0 to
1000000000000
vah
0.001
F060
0
2126
Phase C Vahour
0 to
1000000000000
vah
0.001
F060
0
2128
Reserved (8 items)
---
---
---
F001
0
