Page 26
26
1B1E
...Repeated for module number 22
1B44
...Repeated for module number 23
1B6A
...Repeated for module number 24
1B90
...Repeated for module number 25
1BB6
...Repeated for module number 26
1BDC
...Repeated for module number 27
1C02
...Repeated for module number 28
1C28
...Repeated for module number 29
1C4E
...Repeated for module number 30
Power (Read Only) (30 modules)
1D00
Three Phase Real Power
-1000000000000
to 1000000000000
W
0.001
F060
0
1D02
Phase A Real Power
-1000000000000
to 1000000000000
W
0.001
F060
0
1D04
Phase B Real Power
-1000000000000
to 1000000000000
W
0.001
F060
0
1D06
Phase C Real Power
-1000000000000
to 1000000000000
W
0.001
F060
0
1D08
Three Phase Reactive Power
-1000000000000
to 1000000000000
var
0.001
F060
0
1D0A
Phase A Reactive Power
-1000000000000
to 1000000000000
var
0.001
F060
0
1D0C
Phase B Reactive Power
-1000000000000
to 1000000000000
var
0.001
F060
0
1D0E
Phase C Reactive Power
-1000000000000
to 1000000000000
var
0.001
F060
0
1D10
Three Phase Apparent Power
-1000000000000
to 1000000000000
VA
0.001
F060
0
1D12
Phase A Apparent Power
-1000000000000
to 1000000000000
VA
0.001
F060
0
1D14
Phase B Apparent Power
-1000000000000
to 1000000000000
VA
0.001
F060
0
1D16
Phase C Apparent Power
-1000000000000
to 1000000000000
VA
0.001
F060
0
1D18
Three Phase Power Factor
-0.999 to 1
---
0.001
F013
0
1D19
Phase A Power Factor
-0.999 to 1
---
0.001
F013
0
1D1A
Phase B Power Factor
-0.999 to 1
---
0.001
F013
0
1D1B
Phase C Power Factor
-0.999 to 1
---
0.001
F013
0
1D1C
Reserved (4 items)
---
---
---
F001
0
1D20
...Repeated for module number 2
1D40
...Repeated for module number 3
1D60
...Repeated for module number 4
1D80
...Repeated for module number 5
1DA0
...Repeated for module number 6
1DC0
...Repeated for module number 7
1DE0
...Repeated for module number 8
1E00
...Repeated for module number 9
1E20
...Repeated for module number 10
1E40
...Repeated for module number 11
1E60
...Repeated for module number 12
1E80
...Repeated for module number 13
1EA0
...Repeated for module number 14
