06D2
Breaker Mechanical Life 100 Ack
0 to 4294967295
---
1
F722
0
06D4
Bus Differential Trip Alarm State
0 to 4294967295
---
1
F722
0
06D6
Bus Differential Trip Alarm Ack
0 to 4294967295
---
1
F722
0
06D8
Bus Differential Alarm State
0 to 4294967295
---
1
F722
0
06DA
Bus Differential Alarm Ack
0 to 4294967295
---
1
F722
0
06DC
Multi Source Ground Fault Trip Alarm State
0 to 4294967295
---
1
F722
0
06DE
Multi Source Ground Fault Trip Alarm Ack
0 to 4294967295
---
1
F722
0
06E0
Multi Source Ground Fault Alarm State
0 to 4294967295
---
1
F722
0
06E2
Multi Source Ground Fault Alarm Ack
0 to 4294967295
---
1
F722
0
06E4
Hardware Synch Card Lost State
0 to 4294967295
---
1
F722
0
06E6
Hardware Synch Card Lost Ack
0 to 4294967295
---
1
F722
0
06E8
Reserved
0 to 4294967295
---
1
F722
0
06EA
Compartment ID Button Missing Alarm State
0 to 4294967295
---
1
F722
0
06EC
Reserved
0 to 4294967295
---
1
F722
0
06EE
Compartment ID Button Missing Alarm Ack
0 to 4294967295
---
1
F722
0
06F0
Control Alarm State
0 to 4294967295
---
1
F722
0
06F2
Control Alarm Ack
0 to 4294967295
---
1
F722
0
06F4
Redundant CPU Node Comm Loss State
0 to 4294967295
---
1
F722
0
06F6
Redundant CPU Node Comm Loss Ack
0 to 4294967295
---
1
F722
0
06F8
Redundant CPU Hardware Synch Loss State
0 to 4294967295
---
1
F722
0
06FA
Redundant CPU Hardware Synch Loss Ack
0 to 4294967295
---
1
F722
0
06FC
Discrete IO Misconfigured State
0 to 4294967295
---
1
F722
0
06FE
Discrete IO Misconfigured Ack
0 to 4294967295
---
1
F722
0
Voltage (Read Only) (30 modules)
1000
Phase AG Voltage RMS
0 to 999999.999
V
0.001
F060
0
1002
Phase BG Voltage RMS
0 to 999999.999
V
0.001
F060
0
1004
Phase CG Voltage RMS
0 to 999999.999
V
0.001
F060
0
1006
Phase AB or AC Voltage RMS
0 to 999999.999
V
0.001
F060
0
1008
Phase BC or BA Voltage RMS
0 to 999999.999
V
0.001
F060
0
100A
Phase CA or CB Voltage RMS
0 to 999999.999
V
0.001
F060
0
100C
Reserved (50 items)
---
---
---
F001
0
103E
...Repeated for module number 2
107C
...Repeated for module number 3
10BA
...Repeated for module number 4
10F8
...Repeated for module number 5
1136
...Repeated for module number 6
1174
...Repeated for module number 7
11B2
...Repeated for module number 8
11F0
...Repeated for module number 9
122E
...Repeated for module number 10
126C
...Repeated for module number 11
12AA
...Repeated for module number 12
12E8
...Repeated for module number 13
1326
...Repeated for module number 14
