Source Demand (Read Only) (30 modules)
35BA
SRC x Demand Log Records Since Last Clear
0 to 4294967295
---
1
F003
0
35BC
SRC x Demand Log Interval Records Available
0 to 4294967295
---
1
F003
0
35BE
SRCx Source Demand Reserved (10 items)
0 to 4294967295
---
1
F001
0
35C8
...Repeated for module number 2
35E4
...Repeated for module number 3
3600
...Repeated for module number 4
361C
...Repeated for module number 5
3638
...Repeated for module number 6
3654
...Repeated for module number 7
3670
...Repeated for module number 8
368C
...Repeated for module number 9
36A8
...Repeated for module number 10
36C4
...Repeated for module number 11
36E0
...Repeated for module number 12
36FC
...Repeated for module number 13
3718
...Repeated for module number 14
3734
...Repeated for module number 15
3750
...Repeated for module number 16
376C
...Repeated for module number 17
3788
...Repeated for module number 18
37A4
...Repeated for module number 19
37C0
...Repeated for module number 20
37DC
...Repeated for module number 21
37F8
...Repeated for module number 22
3814
...Repeated for module number 23
3830
...Repeated for module number 24
384C
...Repeated for module number 25
3868
...Repeated for module number 26
3884
...Repeated for module number 27
38A0
...Repeated for module number 28
38BC
...Repeated for module number 29
38D8
...Repeated for module number 30
Source Status (Read Only) (30 modules)
5000
SRC x Node ID
0 to 29
---
1
F001
0
5001
Reserved (3 items)
---
---
---
F001
0
5004
SRC x Frame Rating
0 to 65535
---
1
F001
0
5005
SRC x CT Rating
0 to 65535
---
1
F001
0
5006
SRC x Breaker Type
0 to 1
---
1
F715
0 (UL)
5007
SRC x NodeProt Protection Config
0 to 65535
---
1
F705
0
5008
SRC x Node Firmware Version
0 to 655.35
---
0.01
F001
0
5009
SRC x Hardware Version
0 to 255
---
1
F001
0
500A
SRC x Message Protocol Version
0 to 655.35
---
0.01
F001
0
