37
6644
...Repeated for module number 16
66EA
...Repeated for module number 17
6790
...Repeated for module number 18
6836
...Repeated for module number 19
68DC
...Repeated for module number 20
6982
...Repeated for module number 21
6A28
...Repeated for module number 22
6ACE
...Repeated for module number 23
6B74
...Repeated for module number 24
6C1A
...Repeated for module number 25
6CC0
...Repeated for module number 26
6D66
...Repeated for module number 27
6E0C
...Repeated for module number 28
6EB2
...Repeated for module number 29
6F58
...Repeated for module number 30
Source Commands (Read/Write Command) (30 modules)
7000
SRC x Open Breaker
0 to 1
---
1
F126
0 (No)
7001
SRC x Close Breaker
0 to 1
---
1
F126
0 (No)
7002
SRC x Trip Breaker
0 to 1
---
1
F126
0 (No)
7003
SRC x Clear Energy
0 to 1
---
1
F126
0 (No)
7004
Reserved
---
---
---
F001
0
7005
SRC x Remote Lockout Enable
0 to 1
---
1
F126
0 (No)
7006
SRC x Remote Lockout Reset
0 to 1
---
1
F126
0 (No)
7007
SRC x ATO Mode Enabled
0 to 1
---
1
F126
0 (No)
7008
SRC x Command Reserved (42 items)
0 to 65535
---
1
F001
0
7032
...Repeated for module number 2
7064
...Repeated for module number 3
7096
...Repeated for module number 4
70C8
...Repeated for module number 5
70FA
...Repeated for module number 6
712C
...Repeated for module number 7
715E
...Repeated for module number 8
7190
...Repeated for module number 9
71C2
...Repeated for module number 10
71F4
...Repeated for module number 11
7226
...Repeated for module number 12
7258
...Repeated for module number 13
728A
...Repeated for module number 14
72BC
...Repeated for module number 15
72EE
...Repeated for module number 16
7320
...Repeated for module number 17
7352
...Repeated for module number 18
7384
...Repeated for module number 19
