Appendices
GE Z ENITH C ONTROLS
MDU Owner’s Manual
601 S HILOH R OAD January 2013
P LANO , TX 75074 Page 48
10.0 Appendices
10.1. Appendix A – MDU Input Breaker Sizing Chart
Main Breaker Amperage Rating Chart
I
NPUT
V
OLTAGE
T RANSFORMER LESS
GE Z ENITH
kVA 208/120 Vac 208 Vac 480 Vac 600 Vac
15 60 Amp 60 Amp 30 Amp 20 Amp
30 110 Amp 110 Amp 50 Amp 40 Amp
50 175 Amp 200 Amp 80 Amp 70 Amp
75 300 Amp 300 Amp 125 Amp 100 Amp
100 350 Amp 400 Amp 175 Amp 125 Amp
125 500 Amp 500 Amp 200 Amp 175 Amp
150 600 Amp 600 Amp 250 Amp 200 Amp
200 700 Amp 800 Amp 350 Amp 250 Amp
225 800 Amp 800 Amp 400 Amp 300 Amp
300 N/A N/A 500 Amp 450 Amp
400 N/A N/A 700 CF
500 N/A N/A 800 Amp CF
625 N/A N/A 1000 CF
750 N/A N/A 1200 CF
