Installation Procedures
GE Z
ENITH
C
ONTROLS
MDU Owner’s Manual
601 S
HILOH
R
OAD
January 2013
Plano, TX 75074
Page 22
Country
Color coding (Phase A,B,C)
United States (US)
Black, Red Blue
Canada
Red, Black, Blue
United Kingdom (UK)
Red, Blue, Yellow
13. Connect the ground wire (green or green with yellow tracer) to the distribution panel
ground bus.
14. If the cable requires a neutral wire (white), connect this wire to the distribution panel
neutral bus.
15. Checks to make sure all connections are securely tightened.
16. Remove the blank fillers from the distribution cover panels for the required circuit
breakers.
17. Reinstall and properly align all panels previously removed.
18. Mark (with pencil) installed breakers on the distribution cover panel identification card.
19. Check for proper phase rotation and voltage before attaching the other end of cable
to its associated equipment.
