System Monitoring
GE Z ENITH C ONTROLS
MDU Owner’s Manual
601 S HILOH R OAD January 2013
Plano, TX 75074 Page 25
Feature Std / Optional
1-V
in
: 1-V
out
, 1-I
out
Std.
1-V
in
: 2-V
out
, 2-I
out
Optional
2-V
in
: 1-V
out
, 1-I
out
Optional
Input Voltage THD Std.
Input Ground Current Std.
Neutral Current Std.
Phase Loss Std.
Ground Fault Alarm Std.
Time & Date Stamp for alarms Std.
Alarm Conditions
Input Frequency (Hz) (Frequency Deviation) Std.
Input Phase Rotation (Phase Rotation Error) Std.
Low Transformer Temperature alarm 180 C Std.
High Transformer Temperature alarm 200 C Std.
High Temperature Shutdown (may be disabled at customer request) Std.
True RMS Metering Std.
Input Voltage - Line to Line (High/Low alarm) Std.
Output Voltage - Line to Line (High/Low alarm) Std.
Output Voltage - Line to Neutral (High/Low alarm) Std.
THD - Input Voltage Std.
Output Current - A,B & C phases (phase loss and high current alarm) Std.
Current - Output neutral (High Current Alarm) Std.
Ground Current (Ground Fault Alarm) Std.
Over-Voltage / Under-Voltage Shutdown Optional
Ground Fault Shutdown Optional
Phase Rotation / Phase Loss Shutdown Optional
