GE Zenith Series Monitor Alarm Description
GE Z ENITH C ONTROLS
MDU Owner’s Manual
601 S HILOH R OAD January 2013
Plano, TX 75074 Page 41
Output Voltage Line
A - Neutral Low
“OUTPUT VOLT AN LOW" If the output voltage on line A-Neutral goes below the
preset level line to Neutral, the unit will alarm.
Output Voltage Line
B - Neutral Low
“OUTPUT VOLT BN LOW" If the output voltage on line B-Neutral goes below the
preset level line to Neutral, the unit will alarm.
Output Voltage Line
C - Neutral Low
“OUTPUT VOLT CN LOW" If the output voltage on line C-Neutral goes below the
preset level line to Neutral, the unit will alarm.
Output Current Line A High "OUTPUT CURR A HIGH" If the output current on line A goes above the preset
level, the unit will alarm.
Output Current Line B High "OUTPUT CURR B HIGH" If the output current on line B goes above the preset
level, the unit will alarm.
Output Current Line C High "OUTPUT CURR C HIGH" If the output current on line 3 goes above the preset
level, the unit will alarm.
Ground Current High "OUTPUT CURR GND
HIGH"
If the ground current goes above the preset level of 10
Amps, the unit will alarm.
Neutral Current High "OUTPUT CURR NEU
HIGH"
If the neutral current goes above the preset level, the
unit will alarm.
Total System kVA High "KVA TOTAL HIGH" If the total system kVA goes above the preset level, the
unit will alarm.
Output Phase A kVA High "KVA A HIGH" If the output kVA on Phase "A" goes above the preset
level, the unit will alarm.
Output Phase B kVA High "KVA B HIGH" If the output kVA on Phase "B" goes above the preset
level, the unit will alarm.
Output Phase C kVA High "KVA C HIGH" If the output kVA on Phase "C" goes above the preset
level, the unit will alarm.
Total System kW High "KW TOTAL HIGH" If the total system kW goes above the preset level, the
unit will alarm.
Output Phase A kW High "KW A HIGH" If the output kW on Phase "A" goes above the preset
level, the unit will alarm.
Output Phase B kW High "KW B HIGH" If the output kW on Phase "B" goes above the preset
level, the unit will alarm.
Output Phase C kW High "KW C HIGH" If the output kW on Phase "C" goes above the preset
level, the unit will alarm.
Emergency Power Off "EPO" This alarm can be activated in by pushing the unit's EPO
button. When EPO button is pushed, the alarm is
activated and he unit’s main input circuit breaker will
then be shunt tripped off line.
Remote Emergency Power Off "REMOTE EPO" This alarm can be activated in by closing the contacts
on the contractor board. When Remote EPO button is
activated, the alarm is activated and he unit’s main
input circuit breaker will then be shunt tripped off line.
