Page 24
TM
AMP1H5
INSTALLATION GUIDE
ZL0115-0A
PAGE 24
©2013 For technical support please contact
01132
DET-785
our GE tech support team at 1-800-GE-1-STOP (1-800-431-7867)
TROUBLESHOOTING
Problem
Cause
Solution
The maintenance wrench icon
appears in the power meter display.
There is a problem with the inputs
to the power meter.
See the Alert sub-menu or the Diagnostic Alert BACnet Binary_Input objects
The display is blank after applying
control power to the meter.
The meter is not receiving
adequate power.
Verify that the meter control power is receiving the required voltage.
Verify that the heart icon is blinking.
Check the fuse.
The data displayed is inaccurate.
Incorrect setup values
Verify the values entered for power meter setup parameters (CT and PT ratings, system type, etc.). See the
Setup section.
Incorrect voltage inputs
Check power meter voltage input terminals to verify adequate voltage.
Power meter is wired improperly.
Check all CTs and PTs to verify correct connection, PT polarity, and adequate power. See the Wiring Diagrams
section for more information.
Cannot communicate with power
meter from a remote personal
computer.
Power meter address is incorrect.
Verify that the meter is correctly addressed. See the Setup section.
Power meter baud rate is incorrect. Verify that the baud rate of the meter matches that of all other devices on its communications link (see Setup
section).
Communications lines are
improperly connected.
Verify the power meter communications connections. See the Communications section.
Verify the terminating resistors are properly installed on both ends of a chain of units. Do not use a terminator
on units in the middle of a chain.
Verify shield ground connection between all units.
CHINA ROHS COMPLIANCE INFORMATION (EFUP TABLE)
部件名称
产品中有毒有害物质或元素的名称及含量Substances
铅 (Pb) 汞 (Hg)
镉 (Cd)
六价铬 (Cr(VI))
多溴联苯(PBB)
多溴二苯醚(PBDE)
电子线路板
X
O
O
O
O
O
O = 表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下.
X = 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出SJ/T11363-2006标准规定的限量要求.
Z000057-0A
