AMP1H5 INSTALLATION GUIDE
ZL0115-0A PAGE 19 ©2013 For technical support please contact 01132
DET-785 our GE tech support team at 1-800-GE-1-STOP (1-800-431-7867)
# Object_Name Description R/W NV Units Range Additional information
AI16 Volts_BC Voltage Phase B-C R Volts
AI17 Volts_AC Voltage Phase A-C R Volts
AI18 Volts_AN Voltage Phase A-N R Volts
AI19 Volts_BN Voltage Phase B-N R Volts
AI20 Volts_CN Voltage Phase C-N R Volts
AI21 Current_A Current Phase A R Amps
AI22 Current_B Current Phase B R Amps
AI23 Current_C Current Phase C R Amps
AI24 Reserved_AI24 Reserved R n/a Returns QNAN or any value
AI25 Frequency Frequency R Hz 45.0-65.0 Returns QNAN if frequency is out of range (or no voltage
input present on Phase A)
AI26 kVAh Apparent Energy
Consumption
R NV kVAh 0 - 3.4+E38 The UNITS property of object AI26 reports that these
units are kWh because there is no unit type in the
BACnet standard for kVAh.
AI27 kVARh Reactive Energy
Consumption
R NV kVARh 0 - 3.4+E38 The UNITS property of object AI27 reports that these
units are kWh because there is no unit type in the
BACnet standard for kVARh.
AI28 kVA_A Apparent Power
Phase A
R kVA 0 - Max_Power (AI45)
AI29 kVA_B Apparent Power
Phase B
R kVA 0 - Max_Power (AI45)
AI30 kVA_C Apparent Power
Phase C
R kVA 0 - Max_Power (AI45)
AI31 KVAR_A Reactive Power
Phase A
R kVAR 0 - Max_Power (AI45)
AI32 KVAR_B Reactive Power
Phase B
R kVAR 0 - Max_Power (AI45)
AI33 KVAR_C Reactive Power
Phase C
R kVAR 0 - Max_Power (AI45)
AI34 KW_Present_
Demand
Total Real Power
Present Demand
R kW 0 - Max_Power (AI45)
AI35 KVAR_Present_
Demand
Total Reactive Power
Present Demand
R kVAR 0 - Max_Power (AI45)
AI36 KVA_Present_
Demand
Total Apparent
Power Present
Demand
R kVA 0 - Max_Power (AI45)
AI37 KW_Max_
Demand
Total Real Power
Maximum Demand
R NV kW 0 - Max_Power (AI45) This retains the largest value measured for Total Real
Power Demand (AI34) for any single demand interval
since the Max Demand were last explicitly reset via
AV1 (this is also reset when the demand interval is
changed).
AI38 KVAR_Max_
Demand
Total Reactive Power
Maximum Demand
R NV kVAR 0 - Max_Power (AI45) This retains the largest value measured for Total
Reactive Power Demand (AI35) for any single demand
interval since the Max Demand were last explicitly
reset via AV1 (this is also reset when the demand
interval is changed).
AI39 KVA_Max_
Demand
Total Apparent
Power Maximum
Demand
R NV kVA 0 - Max_Power (AI45) This retains the largest value measured for Total
Apparent Power Demand (AI36) for any single demand
interval since the Max Demand were last explicitly
reset via AV1 (this is also reset when the demand
interval is changed).
