Legend
R/W
R=read only; R/W=read or write
NV
Value is stored in non-volatile memory. The value are still available if the meter experiences a power loss and reset.
Units
Lists the physical units that a register holds.
Device Object
Property
R/W
NV
Value Returned
Additional information
Object_Identifier
R/W
NV
Device
n is the 7 digit ID # set in the ID1 & ID2 setup screens on the meter. The BACnet
Device ID is a decimal number from 1 to 4,193,999 that can be entered or viewed
on the user screens or through this property. The default value set at the factory is
a psuedo-random number from 1,000,000 to 3,097,151 to reduce the likelihood of
conflicts if multiple units are installed using their default IDs.
Object_Type
R
NV
Device (8)
Object_Name
R
NV
GE AMP1xx Series Energy Meter - S/N:
Vendor_Name
R
NV
GE Industrial Solutions
Vendor_Identifier
R
NV
276
Model_Name
R
NV
AMP1H5 Energy Meter
Firmware_Revision
R
NV
“xyyy”.
This is the BACnet processor firmware version in the format
decimal point between the first two digits (x.yyy)
Application_Software_ Version
R
NV
“RS= xyyy, OS=xyyy, BACnet Gateway=xyyy”
The format
Location
R/W
NV
Limted to 64 Characters - Default value is “Installed location not yet identified”
Description
R
NV
GE AMP1H5 Energy Meter S/N: number> Protocol_Version R NV 1 BACnet Protocol Version 1 Protocol_Revsion R NV 4 BACnet Protocol Revision 4 Local_Date R Date Set via BACnet Time Synchronization only - reverts to Jan 1, 2000 if control power drops Local_Time R Time Set via BACnet Time Synchronization only - reverts to 12:00:00 AM if control power drops Segmentation_Supported R NV NO_SEGMENTATION (3) Segmentation is not supported Max_Master R/W NV 1-127 (Factory Default is 127) Highest possible MAC Address for Master nodes on the local MS/TP network Max_Info_Frames R NV 1 Maximum number of information frames allowed before passing the MS/TP token Max_APDU_Length_Accepted R NV 480 APDU_Timeout R NV 60000 Number_of_APDU_Retries R NV 0 System_Status R NV Operational (0) Protocol_Sevices_Supported R NV 0b0000000000001011010000000000000 011110000 Protocol_Object_Types_Supported R NV 0b1011000010000000000010000000000 Object_List R NV DE1,AI1,AI2,AI3,AI4,AI5,AI6,AI7,AI8,AI9,AI1 0,AI11,AI12,AI13,AI14,AI15,AI16,AI17,AI18 ,AI19,AI20,AI21,AI22,AI23,AI24,AI25,AI26 ,AI27,AI28,AI29,AI30,AI31,AI32,AI33,AI34 ,AI35,AI36,AI37,AI38,AI39,AI40,AI41,AI42 ,AI43,AI44,AI45,AI46,AI47,AI48,AI49,AI50 ,AI51,AI52,AV1,AV2,AV3,AV4,AV5,AV6,AV 7,AV8,AV9,AV10,AV11,BI1,BI2,BI3,BI4,BI5, BI6,BI7,BI8,BI9,BI10,BI11,BI12,BI13,BI14,B I15,TL1,TL2,TL3 Device_Address_Binding R NV {} Database_Revsion R NV 0
