3 events, Events – GE Industrial Solutions TLE Series 225-500 User Manual User Manual
Page 30
Critical Power
Modifications reserved
Page 30/90
GE_UPS_USM_TLE_SUL_M22_M50_1US_V010.docx
User Manual TLE Series 225 - 500 UL S1
6.3 EVENTS
EVENTS
The EVENTS mode is entered any time the
“EVENTS” key is pressed.
The LCD will display a series of screens
corresponding to the last 511 events (User
Log).
In this mode the keys perform the following functions:
Shows the main screen MEASURES.
See Section 6.2.
Return to HOME screen.
Shows the main screen SETUP.
See Section 6.4.
Shows the main screen COMMANDS.
See Section 6.5.
Shows the operating status of the RPA PARALLEL SYSTEM.
See Section 6.6.
Key to reset general alarm and buzzer.
Shows the screen User Events.
Shows the screen Service Events. Reserved for the Service Center.
Shows the previous 50 events.
Shows the previous 5 events.
Shows the next 5 events.
Shows the next 50 events.
