- Setting Flag
0x30: Set OK
0x31: Not in Setting mode (in Run mode)
0x39: Set NG
5.3.6.3 Check ADC Input Port Setting Command
Command Data Remark
Byte Size 2 1
“10”
( 0x31, 0x30 )
Check the ADC
setting
0x30: Fixed to a dummy
value
Check the
threshold level
value of an input
ADC port.
5.3.6.4 Response for Check ADC Input Port Setting command
- Same as "5.3.6.2 Response for Set Port command".
- The setting field is always OK (0x30).
- The factory default value in Level Input mode is set to "0000".
5.3.7 Port Enable Setting
5.3.7.1 Set Port Enable command
Command Data Remark
Byte Size 2 34
“11”
( 0x31, 0x31 )
Set to Enable.
Port Enable/Disable setting data
Set all ports to
Enable/Disable.
- Data
Field Data Order Port Data Content
1 A1
2 A2
3 A3
ADC Port
4 A4
0x31: Level Input mode
0x32: Switch Input mode
