- NAK Response
START
FLAG
LENGTH FUNCTION DATA
LRC
(BCC)
END
FLAG
Byte
Size
1 2 2 3 2 2
Start of the
Command
Block, 0x3A
( “:” )
The length from
FUNCTION field
to DATA field
Response
“00”
0x30,0x30
NAK
Data
“NAK”
0x4E,
0x41,
0x4B
XOR from
START
FLAG field to
DATA field
CR (0x0D)
LF (0x0A)
HOST RHIO
-------------------------------------------------
Command
Send Response if it receives the correct command set
Send NAK Response (BCC Error or Timer out or Length calculation error)
-. Users have to write code to send the command again or display NAK status if the program
receives NAK Response.
* NOTE: In the following descriptions, each port is indicated as below:
- Input Port: I1 - I12
- ADC Input: A1 - A4 (Level Input and Switch Input modes)
- Output Port: O1 - O10
5.3.2 ON/OFF Control
5.3.2.1 ON/OFF Control Command
Command Data Remark
Byte Size 2
“01”
( 0x30, 0x31 )
ON/OFF control
10-point output masking and
ON/OFF control data
Send output points to set
ON/OFF in a batch.
