Appendices

Vlinx MESR321 Modbus Gateway

58

MESR321-xx_R001_2113_m

www.bb-elec.com

www.bb-europe.com


Controls, Indicators and Connector Specifications

Switches

Reset button

Hold in for 0 to 2 seconds for
hardware reset
Hold in for 2 to 10 seconds for
Console Mode (Do a hardware reset
or recycle power to exit Console
Mode)
Hold in for more than 10 seconds to
reset to factory defaults

Indicators

Serial LED

Color = Green
On = Port open
Blink = Data traffic

RJ45 Ethernet Link

LED

Color = Green
On = 100BaseTX
Off = 10BaseT
Blink = Data traffic

Ready LED

Color = Green
Blink (once per second) = System in
Normal Mode
Off = System in Console Mode

Fiber Ethernet Link

LED

Off= No connection
On = 100BaseFX connection

Connectors

10BaseT/100BaseT

X Ethernet

Single RJ-45F (8 pin)

LC fiber

LC connector

Serial

One DB9M (RS-232) connector and
one pluggable lockable 5.08 mm
terminal (Rs-422/485)

DC Power

One barrel plug and one terminal
block
