Setup and Connections Vlinx MESR321 Modbus Gateway
14
MESR321-xx_R001_2113m
www.bb-elec.com
www.bb-europe.com
Network Connection (10BaseT/100BaseTX)
When connecting a Modbus gateway equipped with a 10BaseT/100BaseTX
network connection (RJ45 connector) a standard network cable is connected
from the Modbus gateway to a network drop. PCs configuring and/or
communicating with the Modbus gateway are also connected to the network.
Fiber Optic Connection
When connecting a Modbus gateway equipped with a fiber optic interface
to a fiber optic link the appropriate fiber optic cable must be connected between
the Modbus gateway and the network interface.
MESR321 Configuration Connections
MESR321s can be configured over the network or via a serial port.
