Upgrading Firmware Vlinx MESR321 Modbus Gateway
43
MESR321-xx_R001_2113m
www.bb-elec.com
www.bb-europe.com
4 4 . . U U p p g g r r a a d d i i n n g g F F i i r r m m w w a a r r e e
Occasionally, updated firmware may become available for your Modbus gateway.
The firmware can be upgraded using the Vlinx Manager software. The following
procedure describes the firmware updating process:
1. Click the Upgrade button to open the Firmware Upgrade dialog box.
Figure 42. Firmware Upgrade Dialog Box
The name of the currently selected Modbus gateway appears in the top drop
down list. Other Modbus gateways (that have already been discovered) can
be selected from the drop down list, if desired.
The current firmware version of the selected Modbus gateway is shown in the
text below the Modbus gateway name.
Information about the selected firmware file is shown in the third text box.
