DS2132A/Q
041295 9/17
COMMAND BYTE OPTIONS Table 3
[FF]
No update
[00]
No update
[BE]
Idle
[08]
Enter Loopback mode
[09]
Exit Loopback mode
[04]
Enter Power-Down mode
[05]
Exit Power-Down mode
[4A]
Set recording path gain to +30 dB
[49]
Set recording path gain to +27 dB
[48]
Set recording path gain to +24 dB
[47]
Set recording path gain to +21 dB
[46]
Set recording path gain to +18 dB
[45]
Set recording path gain to +15 dB
[44]
Set recording path gain to +12 dB
[43]
Set recording path gain to +9 dB
[42]
Set recording path gain to +6 dB
[41]
Set recording path gain to +3 dB
[40]
Set recording path gain to 0 dB
[5F]
Set recording path gain to -3 dB
[5E]
Set recording path gain to -6 dB
[5D]
Set recording path gain to -9 dB
[5C]
Set recording path gain to -12 dB
[5B]
Set recording path gain to -15 dB
[5A]
Set recording path gain to -18 dB
[59]
Set recording path gain to -21 dB
[58]
Set recording path gain to -24 dB
[57]
Set recording path gain to -27 dB
[56]
Set recording path gain to -30 dB
[80]
Generate DTMF “0” (941+1336 Hz)
[81]
Generate DTMF “1” (697+1209 Hz)
[82]
Generate DTMF “2” (697+1336 Hz)
[83]
Generate DTMF “3” (697+1477 Hz)
[84]
Generate DTMF “4” (770+1209 Hz)
[85]
Generate DTMF “5” (770+1336 Hz)
[86]
Generate DTMF “6” (770+1477 Hz)
[87]
Generate DTMF “7” (852+1209 Hz)
[90]
Generate Dial tone (350+440 Hz)
[91]
Generate Ringing tone (480+440 Hz)
[94]
Generate bright musical note “A” (440+1320 Hz)
[95]
Generate bright musical note “B” (494+1482 Hz)
[96]
Generate bright musical note “C” (523+1569 Hz)
[97]
Generate bright musical note “D” (587+1761 Hz)
[97]
Generate bright musical note “D” (587+1761 Hz)
[98]
Generate bright musical note “E” (659+1977 Hz)
[99]
Generate bright musical note “F” (698+2094 Hz)
[9A]
Generate bright musical note “G” (784+2352 Hz)
[B4]
Generate musical note “A” (440 Hz)
[B5]
Generate musical note “B” (494 Hz)
[B6]
Generate musical note “C” (523 Hz)
[B7]
Generate musical note “D” (587 Hz)
[B8]
Generate musical note “E” (659 Hz)
[B9]
Generate musical note “F” (698 Hz)
[BA]
Generate musical note “G” (784 Hz)
[9B]
Generate bright musical note “A” one octave
higher (880+2640 Hz)
[9C]
Generate bright musical note “B” one octave
higher (988+2974 Hz)
[BB]
Generate musical note “A” one
octave higher (880 Hz)
[BC]
Generate musical note “B” one octave
higher (988 Hz)
[25]
Record at Standard rate (9.8Kbps)
[27]
Record at Extended rate (4.9Kbps)
[28]
Playback at Standard rate (9.8Kbps)
or Premium Rate (16Kbps) with echo
cancellation enabled
[2A]
Playback at Extended rate (4.9Kbps)
or Intermediate Rate (8Kbps) with echo
cancellation enabled
[23]
Record at Intermediate rate (8Kbps)
[21]
Record at Premium rate (16Kbps)
[20]
Playback at Standard rate (9.8 Kbps) or
Premium rate [16Kbps] with echo
cancellation disabled
[22]
Playback at Extended rate (4.9Kbps) or
Intermediate rate (8Kbps) with echo
cancellation disabled
[6A]
Set playback path gain to +30 dB
[69]
Set playback path gain to +27 dB
[68]
Set playback path gain to +24 dB
[67]
Set playback path gain to +21 dB
[66]
Set playback path gain to +18 dB
[65]
Set playback path gain to +15 dB
[64]
Set playback path gain to +12 dB
[63]
Set playback path gain to +9 dB
[62]
Set playback path gain to +6 dB
[61]
Set playback path gain to +3 dB
[60]
Set playback path gain to 0 dB
[7F]
Set playback path gain to -3 dB
[7E]
Set playback path gain to -6 dB
[7D]
Set playback path gain to -9 dB
[7C]
Set playback path gain to -12 dB
[7B]
Set playback path gain to -15 dB
[7A]
Set playback path gain to -18 dB
[79]
Set playback path gain to -21 dB
[78]
Set playback path gain to -24 dB
[77]
Set playback path gain to -27 dB
[76]
Set playback path gain to -30 dB
[88]
Generate DTMF “8” (852+1336 Hz)
[89]
Generate DTMF “9” (852+1477 Hz)
