DS2132A/Q
041295 12/17
ABSOLUTE MAXIMUM RATINGS*
Voltage on Any Pin Relative to Ground -1.0V to +7.0V
Operating Temperature 0 ° C to 70 ° C
Storage Temperature -55 ° C to +125 ° C
Soldering Temperature 260 ° C for 10 seconds
* This is a stress rating only and functional operation of the device at these or any other conditions above
those indicated in the operation sections of this specification is not implied. Exposure to absolute maxi-
mum rating conditions for extended periods of time may affect reliability.
RECOMMENDED DC OPERATING CONDITIONS (0
°
C to 70
°
C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Logic 0 V
IL
-0.3 0.8 V
Logic 1 V
IH
2.0 V
CC
+0.3 V
Supply V
CC
4.5 5.5 V
CAPACITANCE (t
A
= 25 ° C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Input Capacitance C
IN
5 pF
Output Capacitance C
OUT
10 pF
DC ELECTRICAL CHARACTERISTICS (0
°
C to 70
°
C; V
CC
= 5V + 10%)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Active Supply Current I
DDA
35 40 mA 1,2
Input Leakage I
LI
-1.0 +1.0 µ A
Output Leakage I
LO
-1.0 -1.0
µ
A 3
Output Current (2.4 V) I
OH
-1.0 -1.0 mA
Output Current (0.4V) I
OL
+4.0 mA
Power-Down Current I
PD
1 mA 1,2,4
NOTES:
1. V
CC
= 5.5V; CLK=2.048 MHz; MCLK=16 MHz.
2. Outputs open; inputs swinging full supply levels.
3. PCMOUT and CDOUT are 3-stated.
4. Power-down mode.
