I5216 SERIES
Advanced Information
PRELIMINARY
Publication Release Date: November 30, 2001
- 65 Revision A1
I
2
S PARAMETERS (all values in nano seconds)
Transmitter Receiver
Lower Limit Upper Limit Lower Limit Upper Limit
Parameter
MIN MAX MIN MAX MIN MAX MIN MAX
NOTES
Bit Clock period T 325 325
High time t
HC
114 114
Low time t
LC
114 114
Rise time t
RC
49
Delay t
dtr
260
Hold time t
htr
100
Set-up time t
sr
65
Hold time t
hr
0
PCM TIMING DIAGRAMS
