I5216 SERIES
Advanced Information
PRELIMINARY
Publication Release Date: November 30, 2001
- 39
Revision A1
SPEAKER AND AUX OUT DESCRIPTION
15
14
13 12 11 10 9 8 7 6 5 4 3 2 1 0
CIG2 CIG1 CIG0 AXG1 AXG0 AXPD INS0 OSPD AMT0 CDI1 CDI0 OPS1
OPS0
OPA1
OPA0 VLPD
CFG0
15
14
13 12 11 10 9 8 7 6 5 4 3 2 1 0
VLS1 VLS0 VOL2 VOL1 VOL0 S1S1 S1S0 S1M1 S1M0 S2M1 S2M0 FLS0 FLD1 FLD0 FLPD AGPD
CFG1
15
14
13 12 11 10 9 8 7 6 5 4 3 2 1 0
X
X
X CKD2 COG2 COG1 COG0 CKDV MUTE HPF0 HSR0 I2S0 LAW1 LAW0 DAPD ADPD
CFG2
OPS1 OPS0 SOURCE
0 0
VOL
0 1
DAC
OUT
1 0
FILTO
1 1
SUM2
OPA1
OPA0 SPKR DRIVE
AUX OUT
0
0
Power Down
Power Down
0 1
3.6 V
P-P
@ 150
Ω
Power Down
1 0
23.5 mWatt @ 8
Ω
Power Down
1 1
Power
Down 1 V
P-P
Max @ 5 K
Ω
