See Playback and Stop Cycle on page 62 for details.
DATABYTES
In the I
2
C write mode, the device can accept data sent after the command byte. If a register load option
is selected, the next two bytes are loaded into the selected register. The format of the data is MSB first,
as specified by the I
2
C standard. Thus to load DATA<15:0> into the device, DATA<15:8> is sent first,
the byte is acknowledged, and DATA<7:0> is sent next. The address register consists of two bytes.
The format of the address is as follows:
ADDRESS<15:0> = PAGE_ADDRESS<10:0>, BLOCK_ADDRESS<4:0>
If an analog function is selected, the block address bits must be set to 00000. Digital Read and Write
are block addressable.
When the device is polled with the Read Status command, it will return three bytes of data. The first
byte is the status byte, the next is the upper address byte and the last is the lower address byte. The
status register is one byte long and its bit function is:
STATUS<7:0> = EOM, OVF, READY, PD, PRB, DEVICE_ID<2:0>
The lower address byte will always return the block address bits as zero, either in digital or analog
mode.
The functions of the bits are:
BIT# NAME FUNCTION
7 EOM Indicates whether an EOM interrupt has occurred.
6 OVF Indicates whether an overflow interrupt has occurred.
5 READY Indicates the internal status of the device – if READY is LOW no new
commands should be sent to device.
4 PD Device is powered down if PD is HIGH.
3 PRB Play/Record mode indicator. HIGH=Play/LOW=Record.
2
1
0
DEVICE_ID An internal device ID. This is 001 for the I5216.
It is good practice to read the status register after a Write or Record operation to ensure that the
device is ready to accept new commands. Depending upon the design and the number of pins
available on the controller, the polling overhead can be reduced. If INT\ and RAC are tied to the
microcontroller, the controller does not have to poll as frequently to determine the status of the I5216
