I5216 SERIES

Advanced Information

PRELIMINARY

Publication Release Date: November 30, 2001

-15

Revision A1

CFG1

Bit no.

Signal

Description

D0 (LSB)

AGPD

Power down the Microphone AGC

FLPD

Power down the Filter

FLD0

Set the duration and sample rate of the ChipCorder

FLD1

Set the duration and sample rate of the ChipCorder

FLS0

Select the filter input signal

S2M0

Select Sum Amplifier 2 input

S2M1

Select Sum Amplifier 2 input

S1M0

Select Sum Amplifier 1 input

S1M1

Select Sum Amplifier 1 input

S1S0

Select Sum Amplifier 1 multiplexer

D10

S1S1

Select Sum Amplifier 1 multiplexer

D11

VOL0

Volume Control Setting

D12

VOL1

Volume Control Setting

D13

VOL2

Volume Control Setting

D14

VLS0

Select Volume Control input

D15 (MSB)

VLS1

Select Volume Control input
