I5216 series, Preliminary, Volume control description – Rainbow Electronics ISD5216 User Manual
Page 38: Advanced information
I5216 SERIES
Advanced Information
PRELIMINARY
Publication Release Date: November 30, 2001
- 38
Revision A1
VOLUME CONTROL DESCRIPTION
15
14
13 12 11 10 9 8 7 6 5 4 3 2 1 0
CIG2 CIG1 CIG0 AXG1 AXG0 AXPD INS0 OSPD AMT0 CDI1 CDI0 OPS1 OPS0 OPA1 OPA0 VLPD
CFG0
15
14
13 12 11 10 9 8 7 6 5 4 3 2 1 0
VLS1
VLS0
VOL2
VOL1
VOL0 S1S1 S1S0 S1M1 S1M0 S2M1 S2M0 FLS0 FLD1 FLD0 FLPD AGPD
CFG1
15
14
13 12 11 10 9 8 7 6 5 4 3 2 1 0
X
X
X CKD2 COG2 COG1 COG0 CKDV MUTE HPF0 HSR0 I2S0 LAW1 LAW0 DAPD ADPD
CFG2
VLPD CONDITION
0 Power
Up
1 Power
Down
VLS1 VLS0 SOURCE
0 0
DAC
OUT
0 1
SUM2
1 0
SUM1
1 1
INP
VOL2 VOL1 VOL0 ATTENUATION
0 0 0
0
dB
0 0 1
4
dB
0 1 0
8
dB
0 1 1 12
dB
1 0 0 16
dB
1 0 1 20
dB
1 1 0 24
dB
1 1 1 28
dB
