I5216 SERIES
Advanced Information
PRELIMINARY
Publication Release Date: November 30, 2001
- 54 Revision A1
OPERATING CONDITIONS (Die)
Condition Value
Die operating temperature range (1) 0 0 C to +50 0 C
Supply voltage (V
CC
) (2) +2.7V to +3.3V
Ground voltage (V
SS
) (3) 0V
1. Case temperature 2. V
CC
= V
CCA
= V
CCD
3. V
SS
= V
SSA
= V
SSD
General Parameters
Symbol Parameters Min
(2)
Typ
(1)
Max
(2)
Units Conditions
V
IL
Input Low Voltage V
CC
x
0.2
V
V
IH
Input High Voltage V
CC
x 0.8 V
V
OL
SCL, SDA, SDIO Output Low
Voltage 0.4 V I
OL
= 3 mA
V
OL1
RAC, INT Output Low Voltage 0.4 V I
OL
= 1 mA
V
OH
Output High Voltage V
CC
– 0.4 V I
OL
= -10 µ A
I
CC
V
CC
Current (Operating)
- Playback & A/D + D/A
- Record & A/D + D/A
- CODEC A/D + D/A 30
36
20 50
56
30 mA
mA
mA No Load (3)
No Load (3)
No Load (3)
I
SB
V
CC
Current (Standby) 1 10 µ A (3)
I
IL
Input Leakage Current +/-1 µ A
1. Typical values: T
A
= 25°C and Vcc = 3.0 V.
2. All min/max limits are guaranteed by Winbond via electrical testing or characterization. Not all
specifications are 100 percent tested.
3. V
CCA
and V
CCD
summed together.
