TIMING PARAMETERS
Symbol Parameters Min
(2)
Typ
(1)
Max
(2)
Units Conditions
F
S
Sampling Frequency 8.0
6.4
5.3
4.0 kHz
kHz
kHz
kHz (5)
(5)
(5)
(5)
F
CF
Filter Knee
8.0 kHz (sample rate)
6.4 kHz (sample rate)
5.3 kHz (sample rate)
4.0 kHz (sample rate) 3.7
2.9
2.5
1.8 kHz
kHz
kHz
kHz
Knee Point
(3)(7)
Knee Point (3)(7)
Knee Point (3)(7)
Knee Point (3)(7)
T
REC
Record Duration
8.0 kHz (sample rate)
6.4 kHz (sample rate)
5.3 kHz (sample rate)
4.0 kHz (sample rate) 8.05
10.06
12.15
16.1
min
min
min
min
(6)
(6)
(6)
(6)
T
PLAY
Playback Duration
8.0 kHz (sample rate)
6.4 kHz (sample rate)
5.3 kHz (sample rate)
4.0 kHz (sample rate) 8.05
10.06
12.15
16.1
min
min
min
min
(6)
(6)
(6)
(6)
T
PUD
Power-Up Delay
8.0 kHz (sample rate)
6.4 kHz (sample rate)
5.3 kHz (sample rate)
4.0 kHz (sample rate) 1
1
1
1 msec
msec
msec
msec
T
STOP
OR
PAUSE
Stop or Pause
Record or Play
8.0 kHz (sample rate)
6.4 kHz (sample rate)
5.3 kHz (sample rate)
4.0 kHz (sample rate)
32
40
48
64 msec
msec
msec
msec
