I5216 SERIES
Advanced Information
PRELIMINARY
Publication Release Date: November 30, 2001
- 53 Revision A1
ELECTRICAL CHARACTERISTICS
ABSOLUTE MAXIMUM RATINGS (Packaged Parts)
(1)
Condition Value
Junction temperature 150 0 C
Storage temperature range -65 0 C to +150 0 C
Voltage Applied to any pin (V
SS
- 0.3V) to (V
CC
+ 0.3V)
Voltage applied to any pin (Input current limited to +/-20 mA) (V
SS
– 1.0V) to (V
CC
+ 1.0V)
Lead temperature (soldering – 10 seconds) 300 0 C
V
CC
- V
SS
-0.3V to +5.5V
1. Stresses above those listed may cause permanent damage to the device. Exposure to the absolute
maximum ratings may affect device reliability. Functional operation is not implied at these conditions.
ABSOLUTE MAXIMUM RATINGS (Die)
(1)
Condition Value
Junction temperature 150 0 C
Storage temperature range -65 0 C to +150 0 C
Voltage Applied to any pad (V
SS
- 0.3V) to (V
CC
+ 0.3V)
V
CC
- V
SS
-0.3V to +5.5V
1. Stresses above those listed may cause permanent damage to the device. Exposure to the absolute
maximum ratings may affect device reliability. Functional operation is not implied at these conditions.
OPERATING CONDITIONS (Packaged Parts)
Condition Value
Commercial operating temperature range (1) 0 0 C to +70 0 C
Extended operating temperature (1) -20 0 C to +70 0 C
Industrial operating temperature (1) -40 0 C to +85 0 C
Supply voltage (V
CC
) (2) +2.7V to +3.3V
Ground voltage (V
SS
) (3) 0V
1. Case temperature 2. V
CC
= V
CCA
= V
CCD
3. V
SS
= V
SSA
= V
SSD
