I5216 SERIES
Advanced Information
PRELIMINARY
Publication Release Date: November 30, 2001
-16 Revision A1
CFG2
Bit no. Signal Description
D0 (LSB) ADPD Power down the Analog to Digital converter
D1 DAPD Power down the Digital to Analog converter
D2 LAW0 Select digital
µ
-Law or A-Law input/output format
D3 LAW1 Select digital
µ
-Law or A-Law input/output format
D4 I2S0 Select the I2S interface
D5 HSR0 Enable the high sample rate mode
D6 HPF0 Enable High Pass Filter
D7 MUTE Mute the CODEC A/D and D/A path
D8 CKDV Divide MCLK by 2560 or 1728 for 8 kHz ChipCorder sample rate
D9 COG0 Output gain setting for the Digital to Analog converter
D10 COG1 Output gain setting for the Digital to Analog converter
D11 COG2 Output gain setting for the Digital to Analog converter
D12 CKD2 Divide MCLK frequency by 2 or 1
D13 - Reserved
D14 - Reserved
D15 (MSB) - Reserved
