TIMING PARAMETERS (CONT’D)
Symbol Parameters Min
(2)
Typ
(1)
Max
(2)
Units Conditions
T
RAC
RAC Clock Period
8.0 kHz (sample rate)
6.4 kHz (sample rate)
5.3 kHz (sample rate)
4.0 kHz (sample rate)
256
320
386
512 msec
msec
msec
msec
(9)
(9)
(9)
(9)
T
RACLO
RAC Clock Low Time
8.0 kHz (sample rate)
6.4 kHz (sample rate)
5.3 kHz (sample rate)
4.0 kHz (sample rate)
8
10
12.1
16
msec
msec
msec
msec
T
RACM
RAC Clock Period in
Message Cueing Mode
8.0 kHz (sample rate)
6.4 kHz (sample rate)
5.3 kHz (sample rate)
4.0 kHz (sample rate)
500
625
750
1000
msec
msec
msec
msec
TRACML RAC Clock Low Time in
Message Cueing Mode
8.0 kHz (sample rate)
6.4 kHz (sample rate)
5.3 kHz (sample rate)
4.0 kHz (sample rate)
15.6
19.5
23.4
31.2 msec
msec
msec
msec
THD Total Harmonic Distortion
AUX IN to ARRAY,
ARRAY to SPKR
1
1 2
2
%
% @1 KHz at 0TLP,
sample rate = 5.3
KHz
