I5216 SERIES
Advanced Information
PRELIMINARY
Publication Release Date: November 30, 2001
-5
Revision A1
PIN DESCRIPTION
Pin Name
Pin No.
28-pin
TSOP
Pin No.
28-pin
PDIP
Pin No.
28-pin
SOIC
Functionality
RAC
4
25
25
Row Address Clock; an open drain output. The RAC pin goes LOW
T
RACLO
1
before the end of each row of memory, and returns HIGH
at exactly the end of each row of memory.
/INT
5
26
26
Interrupt Output; an open drain output indicating that a set EOM bit
has been found during Playback, or that the chip is in an Overflow
(OVF) condition. This pin remains LOW until a Read Status
command is executed.
MCLK
6
27
27
This pin allows the internal clock of the Voice record/playback
system to be externally driven for enhanced timing precision. This
pin is grounded for most applications. It is required for the CODEC
operation.
SCL
9
2
2
Serial Clock Line is part of the I
2
C serial bus. It is used to clock the
data into and out of the I
2
C interface.
SDA
11
4
4
Serial Data Line is part of the I
2
C serial bus. Data is passed
between devices on the bus over this line.
A0
12
5
7
Input pin that supplies the LSB for the I
2
C Slave Address.
A1
10
3
3
Input pin that supplies the LSB +1 bit for the I
2
C Slave Address.
MIC+
16
9
10
Differential positive Input to the microphone amplifier.
MIC-
17
10
9
Differential negative Input to the microphone amplifier.
MICBS
18
11
8
Microphone Bias Voltage
ACAP
19
12
12
AGC Capacitor connection. Required for the on-chip AGC amplifier.
SP+
22
15
15
Differential Positive Speaker Driver Output.
SP-
20
13
13
Differential Negative Speaker Driver Output. When the speaker
outputs are in use, the AUX OUT output is disabled.
AUX IN
24
17
17
Auxiliary Input. This is one of the gain adjustable analog inputs for
the device.
AUX OUT
25
18
20
Auxiliary Output. This is one the analog outputs for the device.
When this output is in use, the SP+ and SP- outputs are disabled.
SDI
2
23
22
Serial Digital Audio PCM Input.
SDIO
3
24
24
Serial Digital Audio PCM Output or I
2
S Input/Output.
WS
28
21
18
Digital audio PCM Frame sync (FS) or I
2
S Word Sync (WS).
SCK
27
20
19
Digital audio PCM or I
2
S Serial Clock.
V
CCD
7,8
1,28
1,28
Positive Digital Supply pins. These pins carry noise generated by
internal clocks in the chip. They must be carefully bypassed to
Digital Ground to ensure correct device operation.
V
SSD
13,14
6,7
5,6
Digital Ground pins.
V
SSA
1,15,21
8,14,22
11,14,23
Analog Ground pins.
V
CCA
23
16
16
Positive Analog Supply pin. This pin supplies the low level audio
sections for the device. It should be carefully bypassed to Analog
Ground to ensure correct device operation.
NC 26
19
21
No
Connection
1
See parameters section of the datasheet.
