Tower Dryer Operations & Service PARTS LIST
40
COMMERCIAL TOWER DRYER COMMON SERVICE PARTS (CONTINUED)
Part # Description Where Used
GT3-0955 Allen Bradley Inverter, VFD AB PF4 2HP/230V Variable Speed Drive for Unload - Size and Voltage Specific
GT3-0954 Allen Bradley Inverter, VFD AB PF4 2HP/460V Variable Speed Drive for Unload - Size and Voltage Specific
GT3-0953 Allen Bradley Inverter, VFD AB PF4 5HP/230V Variable Speed Drive for Unload - Size and Voltage Specific
GT3-0952 Allen Bradley Inverter, VFD AB PF4 5HP/460V Variable Speed Drive for Unload - Size and Voltage Specific
GT3-0975 Reactor, Line 2HP 230V 7.5 Amp Protects Inverter From Voltage Spikes - Size and Voltage Specific
GT3-0976 Reactor, Line 2HP 460V 3.4 Amp Protects Inverter From Voltage Spikes - Size and Voltage Specific
GT3-0482 Reactor, Line 5HP 230V 15.2 Amp Protects Inverter From Voltage Spikes - Size and Voltage Specific
GT3-0129 Reactor, Line 5HP 460V 7.6 Amp Protects Inverter From Voltage Spikes - Size and Voltage Specific
TD-100077 Horn 120 Weatherproof Alarms When Dryer Shutsdown for Any Reason
756-1213-5 Air Switch Differential JD2-BLUE Mounted in Power Panel - Prove Blower is Running
815-1783-3 Start/Stop/Pilot Kit Complete Start/Stop Switch Kit - Used to Control Legs, Conveyors
GT3-0099 Contact Block for PushButton 1 N.O. CR104PXC1 Replacement N.O. Contact Block for Start Button
756-1415-6 Button, Push-Recess Head GE CR104PB-GOOU3 Replacement Green Start Button (Button Only)
GT3-0100 Contact Block for PushButton 1 N.C. CR104PXCO1 Replacement N.C. Contact Block for Stop Button
756-1414-9 Button, Push-Extended Head GE CR104PB-GOOU2 Replacement Red Stop Button (Button Only)
815-1849-0 Selector Switch, 2POS, 1 N.O./1 N.C. Complete With 1 N.O./1 N.C. Contact Block
Service Parts Kit Standard
Includes The Following Parts:
1 - Igniter (Natural Gas or LP)
1 - Flame Rod (Natural Gas or LP)
1 - ACF Relay
1 - Flame Pac
1 - SS3CP Transformer
1 - Adjustible Plenum Hi-Limit
2 - 36' Overheat (Fixed Hi-Limit)
Service Parts Kit Expanded
Includes the Following Parts:
1 - Complete Kit 1 (GT4-SRVSCH1)
1 - Honeywell Modutrol Motor M7284A 1012
1 - Ounce Gauge
1 - Sensor, Platinum RTD Honeywell
1 - Air Switch
6 - Burner Drill Bits
Service Parts Kits
GT4-SRVSCH1
This Kit Contains essential parts that cannot be bypassed and will
prevent the dryer from running if they fail.
GT4-SRVSCH2
This kit contains all parts in kit 1 plus some additonal parts that
should be kept on hand.
Inverters and Line Reactors
Inverters
NOTE: If dryer is equipped with add on Dryer Master ab ove inverters must b e Power Flex40.
Add an A to end of ab ove part num b er for PF40.
Line Reactors
Useful/Miscellaneous
