13
Tower Dryer Operations & Service
1 2 3
4
5
6
7
8
I. Main Screen
TRI-POINT MOISTURE CONTROLLER
1. Two-hour moisture history chart -
green line for incoming moisture; yellow
line for outgoing moisture; and the red line
is the target moisture.
2. Moisture Control button - to access
the Moisture Control Set-up screen.
3. Data Log button - to access the mois-
ture history data (up to last 30 hours).
4. Back browse button - to scroll the
chart back in time.
5. Forward browse button - to scroll the
chart in forward time
6. Moisture target - To change the mois-
ture target, press within the rectangular area
and key in the new target from the pop-up
keypad.
7. Current moisture coming out of the
dryer.
8. Current moisture coming into the
dryer.
9. Moisture control status - the LED
turns on if the moisture controller is in auto
mode
9
