LUBRICANT CAPACITY
Each reducer has the oil level and oil quantity adjusted according to the mounting position shown in the tables. When replacing the oil, consult
the tables below to determine the proper amount of oil to be installed according to the reducer size and mounting position. Note that this is
approximate and the final level will be adjusted when the reducer is installed. Acceptable oil fill level is within ½ inch of the bottom of the fill
plug threads.
LUBRICATION CAPACITY - SHAFT MOUNT 'CLINCHER' GEARBOXES
MOUNTING POSITION MOUNTING POSITION
Horizontal Vertical Horizontal Vertical
H1 H2 H3 H4 H5 H6 H1 H2 H3 H4 H5 H6
SK 0182NB quarts 0.42 0.63 0.53 0.53 0.58 0.58 SK 1382NB quarts 1.37 1.48 2.01 2.11 2.22 2.43
liters 0.40 0.60 0.50 0.50 0.55 0.55 liters 1.30 1.40 1.90 2.00 2.10 2.30
SK0282NB quarts 0.74 0.85 0.95 0.95 1.16 1.06 SK 2382 quarts 1.80 2.01 1.59 1.59 3.28 2.75
liters 0.70 0.80 0.90 0.90 1.10 1.00 liters 1.70 1.90 1.50 1.50 3.10 2.60
SK 1282 quarts 0.95 0.95 1.00 1.00 1.27 1.37 SK 3382 quarts 4.33 3.49 3.49 3.49 5.92 4.33
liters 0.90 0.90 0.95 0.95 1.20 1.30 liters 4.10 3.30 3.30 3.30 5.60 4.10
SK 2282 quarts 1.74 2.01 1.90 1.90 2.11 2.54 SK 4382 quarts 6.24 5.18 5.18 5.18 8.77 7.19
liters 1.65 1.90 1.80 1.80 2.00 2.40 liters 5.90 4.90 4.90 4.90 8.30 6.80
SK 3282 quarts 3.33 3.44 3.33 3.33 4.33 4.33 SK 5382 quarts 13.21 7.08 8.77 8.77 14.80 12.68
liters 3.15 3.25 3.15 3.15 4.10 4.10 liters 12.50 6.70 8.30 8.30 14.00 12.00
SK 4282 quarts 4.97 5.02 4.97 4.97 5.71 6.45 SK 6382 quarts 17.4 10.1 13.2 14.8 19.0 13.7
liters 4.70 4.75 4.70 4.70 5.40 6.10 liters 16.5 9.6 12.5 14.0 18.0 13.0
SK 5282 quarts 7.93 7.93 7.61 7.61 9.30 9.30 SK 7382 quarts 23.3 16.9 20.1 24.3 26.4 21.1
liters 7.50 7.50 7.20 7.20 8.80 8.80 liters 22 16 19 23 25 20
SK 6282 quarts 18.0 12.7 14.8 10.6 18.5 14.8 SK 8382 quarts 35.9 26.4 31.7 37.0 40.2 33.8
liters 17.0 12.0 14.0 10.0 17.5 14.0 liters 34 25 30 35 38 32
SK 7282 quarts 26.4 21.1 22.2 16.9 28.5 22.2 SK 9382 quarts 77.2 47.6 63.4 68.7 78.2 74.0
liters 25 20 21 16 27 21 liters 73 45 60 65 74 70
SK 8282 quarts 39.1 31.7 32.8 32.8 43.3 34.9 SK 10382 quarts 90 77 85 85 93 93
liters 37 30 31 31 41 33 liters 85 73 80 80 88 88
SK 9282 quarts 78.2 58.1 62.4 72.9 76.1 74.0 SK 11382 quarts 169 148 143 164 222 164
liters 74 55 59 69 72 70 liters 160 140 135 155 210 155
SK 10282 quarts 95 42 87 63 95 95 SK 12382 quarts 169 148 143 164 222 164
liters 90 40 82 60 90 90 liters 160 140 135 155 210 155
SK 11282 quarts 174 153 148 106 206 169
liters 165 145 140 100 195 160
Note: Filling quantities are approximate figures. Oil level must be checked according to oil level plug after final installtion.
Acceptable oil fill level is within 1/2 inch of the bottom of the fill plug threads. For mounting angles not shown, consult factory.
