Grain Systems PNEG-526 - Manual (Page 48)

Tower Dryer Operations & Service PARTS LIST
39
COMMERCIAL TOWER DRYER COMMON SERVICE PARTS (CONTINUED)
Part # Description Where Used
GT3-0620 Switch Set VCS-1 (SOV) Maxon VOS-1 #14-23433 Maxon Switch 3" Valve and Up
GT3-0623 Switch Set VCS-1 (VOS-1) Maxon #14-18428 Maxon Switch 2" Valve and Below
GT3-0619 Switch Set VCS-2 (SOV) Maxon VOS-2 (STO) #14-23434 Double Maxon Switch 3" Valve and up
GT3-0622 Switch Set VCS-2 (VOS-2) Maxon #14-18429 Double Maxon Switch 2" Valve and Below
KD-PVA0005 Solenoid 22055 Solenoid 2" and 3" Non-Motorized Maxon
769-1028-0 Solenoid 23243 Solenoid 4" Non-Motorized Maxon
GT3-0515 CV Valve 2" Controls Flow of Gas to Burner - Size Specific
GT3-0132 Valve, 3" CV Series Controls Flow of Gas to Burner - Size Specific
GT3-0214 Valve, Maxon 4" F CV Controls Flow of Gas to Burner - Size Specific
GT3-0724 Valve Disc for 2" Maxon CV Replacement Part for 2" CV Valve
GT3-0726 Valve Shaft for 2" Maxon CV Replacement Part for 2" CV Valve
769-1024-9 Butterfly Shaft 4" Replacement Part for 4" CV Valve
769-1197-3 O-Ring 2" Shaft Replacement Part for 2" CV Valve
769-1335-9 Adaptor Bushing MR Valve Arm
Round to Square Bushing in 4" Valve Arm That
Connects Arm to Modutrol Motor
756-1534-4 Filter, Line Active 120V AC 2.5A Protects PLC from Spikes and Reduces Noise to PLC
756-2159-9 PLC, AB Rack 10 Slot Back Plane for PLC Cards
756-1795-1 Power Supply, PLC Abradley SLC Power Suply for PLC 120V AC to 24VDC
756-1796-9 PLC, AB SLC 503 CPU 1747-L532 PLC Card - CPU (Has Power, Fault, DH485 Lights)
756-1797-7 PLC, AB SLC Memory Module - Programming Required
Installs in CPU Card - Memory Module That
Holds Program
756-1799-3 PLC, AB SLC Mix AI/O 2 x 2 Card 1746-NI041 First Card to Right of CPU
756-2161-5 PLC, AB RTD Temperture Module Second Card to Right of CPU
756-1801-7 PLC, AB DOX16 Card 1746-OW16 16 Point Output Card
GT3-0944 PLC, AB IOUTX8 Relay 1746-OX8 8 Point Output Card
GT3-0810 PLC, AB DIX16 24VDC 1746-IB16 16 Point Input Card
756-1807-4 PLC, AB Slot Cover Blank - Slot Cover
GT3-1105 Battery, for AB SLC 500 PLC CPU 1747-BA Installs in CPU Card - Battery for Back Up
GT3-0945 OIU, AB PV+ 2711P-RDT10C Touchscreen in Control Panel
GT3-0947 OIU, AB Antiglare 2711P-RG10 Film Antiglare Film for Touchscreen
GT3-0946 Module, OIU AB PV+ LOG. MOD. 2711P-RP
1st Module Attached to Back of Touchscreen -
Contains RAM and Compact Flash Card
GT3-0974 Module, OIU AB PV+ COMM. MOD. 2711P-RN6 Stacked on Back of 1st Module
GT3-0990 OIU, AB 32MB CF Card 2711-PRW1 - Programming Required Inserted into 1st Module
GT3-0991 OIU, 64MB RAM 2711-PRR64 Inserted into 1st Module
GT3-0973 IC, PLC AB Micro 1200 24DCIN 16Out 1762-L40BWA Micro Processor Located Inside Control Panel
056-2323-6 PLC, AB Advanced Interface Module 1761-NET-AIC
Located Inside of Control Panel - Links PLC
to Micro Processor
756-2163-1 PLC, AB Isolated Link Coupler 1747-AIC-DH485
Located inside of Power Panel - Links PPLC
to Micro Processor
Single Switch
Double Switch
CV Valves and Components
PLC and OIU Parts
PLC Parts
OIU Parts
48
