Tower Dryer Operations & Service PARTS LIST
36
COMMERCIAL TOWER DRYER COMMON SERVICE PARTS
Part # Description Where Used
GT3-0036 Bindicator RA4 Low Grain Indicator Located on Upper Sidewall of Dryer
815-1700-5 Bindicator RA6 High Grain Indicator Located on Dryer Roof
756-1150-9 Bindicator Micro-Switch Replacement Switch for Either Bindicator
769-1225-2 Bindicator Paddle Replacement Paddle for Either Bindicator
756-1148-3 Bindicator Motor A-H9A-K-HD Replacement Motor for Either Bindicator
S-8896 Screw, MS #4-40 x 1" SHCS Connects Extension Shaft or Paddle to Bindicator
S-9100 Nut, Nylock #4-40 ZN GR2 Connects Extension Shaft or Paddle to Bindicator
769-1038-9 Bindicator Cover Gasket Replacement Gasket for Either Bindicator
GT1-1119 Bindicator Ext. Rod 12" Standard Extension Rod for RA6 Bindicator
GT1-1473 Bindicator Ext. Shaft 18" Special Length Extension Rod for RA6 Bindicator
GT1-1120 Bindicator Ext. Rod Shield Standard Length Rod Shield (Conduit) for RA6 Bindicator
GT1-1474 Bindicator Ext. Shield 18" Special Length Rod Shield (Conduit) for RA6 Bindicator
806-1667-5 Bindicator Conduit Cap Rod ShieldCap for RA6 Bindicator
769-1039-7 Bindicator Mounting Plate Replacement Mounting Plate for RA4 Bindicator
GT3-0004 Hi-Limit, Fixed 210° 36' Fixed Replacement Hi-Limit for Outside or Inside Overheats
756-1026-1
Thermostat, Hi-Limit Honeywell T675A 1102 160
to 260D Adjustible
Adjustable Plenum Hi-Limit that Monitors the Burner
756-1865-2 P robe 12"
Temperature Based Moisture Probe Mounted in Outside Sidewall
About 1/3 the Way Up the Dryer
756-1866-0 Thermowell 12" Thermowell to Protect Moisture Probe
815-1383-0 RTD Probe Mount Weldment Mount for Above Thermowell and Probe
GT3-0090 Sensor, Platinum RTD Honeywell
Temperature Sensor for Burner Mounted on Inside Wall Across
From the Burner
GT3-0139 Wire, 18/2 Shielded Cable Used for Either Probe Above - Sold Per Foot
602E020-CAT5
Moisture Sensor-Standard Assy (Wide)
W/WR-CAT5E-SH
Top or Bottom Sensor for Tri-Moisture System
WR-CAT5E-SH Cable, Wire CAT5E Shielded Cable Used for Tri-Moisture Sensor - Sold per Foot
815-1935-9 Moisture Sensor Housing Assy
Sample Chute Mounted Below Discharge Hopper and Houses
Tri-Moisture Sensor
GT1-1534 Gate, Slide 2-1/4" - Moisture Sensor Replacement Slide Gate for Moisture Sensor Housing
801-2143-7 Gate, Slide 2-1/2" - Moisture Sensor Box Replacement Slide Gate for Moisture Sensor Housing
801-2144-5 Gate, Slide 2-3/4" - Moisture Sensor Box Replacement Slide Gate for Moisture Sensor Housing
801-2101-5 Gate, Slide 3" - Moisture Sensor Box Replacement Slide Gate for Moisture Sensor Housing
Bindicator
Hi-Limits (Fixed and Adjustible)
RTD, Thermowells, Probes, Moisture Sensors
